Processor |
Intel Core i7-10510U (4C / 8T, 1.8 / 4.9GHz, 8MB)
|
Graphics |
Integrated Intel UHD Graphics
|
Chipset |
Intel SoC Platform
|
Memory |
16GB Soldered DDR4-2666
|
Memory Slots |
Memory soldered to systemboard, no slots, dual-channel
|
Max Memory |
16GB soldered memory, not upgradable
|
Storage |
512GB SSD M.2 2280 PCIe 3.0×4 NVMe Opal2
|
Storage Support |
One drive, up to 512GB M.2 2242 SSD or 2TB M.2 2280 SSD, optional Intel Optane Memory integrated with SSD, M.2
|
Card Reader |
MicroSD Reader
|
Optical |
None
|
Audio Chip |
High Definition (HD) Audio, Realtek ALC3287 codec
|
Speakers |
Stereo speakers, 1W x2, Dolby Audio
|
Camera |
720p with ThinkShutter
|
Microphone |
2x, Array
|
Battery |
Integrated 57Wh
|
Max Battery Life |
MobileMark 2014: 21 hr MobileMark 2018: 14.28 hr JEITA 2.0: 23.1 hr
|
Power Adapter |
65W USB-C
|
DESIGN |
Display |
14″ FHD (1920×1080) IPS 250nits Anti-glare
|
Touchscreen |
None
|
Keyboard |
Non-backlit, Spanish (LA)
|
Case Color |
Black
|
Case Material |
CF Hybrid (Top), Magnesium (Keyboard Cover), Magnesium (Bottom)
|
Dimensions (WxDxH) |
329.0 x 226.15 x 16.7 mm (12.95 x 8.90 x 0.66 inches)
|
Weight |
1.35 kg (2.98 lbs)
|
SOFTWARE |
Operating System |
Windows 10 Pro 64, Spanish
|
Bundled Software |
None
|
CONNECTIVITY |
Ethernet |
100/1000M via Optional Adapter
|
WLAN + Bluetooth |
Intel AX201 11ax, 2×2 + BT5.2
|
WWAN |
None
|
SIM Card |
None
|
NFC |
None
|
Standard Ports |
- 1x side docking connector
- 1x USB-C 3.2 Gen 1 (support data transfer, Power Delivery and DisplayPort 1.2)
- 1x Ethernet extension connector
- 1x USB 3.2 Gen 1
- 1x USB 3.2 Gen 1 (Always On)
- 1x HDMI 1.4b
- 1x headphone / microphone combo jack (3.5mm)
- 1x USB-C 3.2 Gen 2 / Thunderbolt 3 (support data transfer, Power Delivery and DisplayPort 1.2)
|
Optional Ports (configured) |
1x microSD card slot (WLAN model)
|
Monitor Cable |
None
|
SECURITY & PRIVACY |
Smart Card Reader |
None
|
Security Chip |
Discrete TPM 2.0
|
Fingerprint Reader |
Touch Style, Match-on-Chip
|
Physical Locks |
Kensington Security Slot
|
Other Security |
ThinkShutter camera cover
|
MANAGEABILITY |
System Management |
None
|
SERVICE |
Base Warranty |
1-year, Depot
|
Included Upgrade |
3Y Accidental Damage Protection Add On (5PS0A23193), 3Y Onsite upgrade from 1Y Courier/Carry-in (5WS0A14086)
|
ACCESSORIES |
Bundled Accessories |
ThinkPad Ethernet Extension Adapter Gen 2
|
CERTIFICATIONS |
Green Certifications |
- ENERGY STAR 8.0
- TCO
- EPEAT Gold
- RoHS compliant
|
Mil-Spec Test |
MIL-STD-810G military test passed
|
