| CARACTERÍSTICAS DE HARDWARE | |
|---|---|
| Estándares y Protocolos | IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x |
| Interface | • 8 puertos RJ45 10/100/1000 Mbps (los puertos 1–4 admiten 802.3at / af PoE +) • Negociación automática / Auto MDI / MDIX |
| Medios de red | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) |
| Cantidad de ventiladores | Sin ventiladores |
| Fuente de alimentación | • Adaptador de corriente externo (Salida: 53.5 VDC / 1.31 A) |
| Consumo de Poder | • 7.9 W (220 V/50 Hz) (no PD connected) • 79.2 W (220 V/50 Hz) (with 62 W PD connected) |
| Puertos PoE (RJ45) | • Estándar: compatible con 802.3af / at • Puertos PoE: 4 puertos • Suministro PoE total: 62 W * |
| Dimensiones (An x Pr x Al) | 209 x 126 x 26mm (8.2 x 4.9 x 1.0 in) |
| Consumo máximo de energía | • V1: 69.7 W (220 V/50 Hz) (with 62 W PD connected); 7.9 W (220 V/50 Hz) (no PD connected) • V2: 73.8 W (220 V/50 Hz) (with 62 W PD connected) • V3: 77.3 W (110 V/60 Hz) (with 62 W PD connected) |
| Disipación de calor máxima | • V1: 237.82 BTU/hr (220 V/50 Hz) (with 62 W PD connected); 26.95 BTU/hr (220 V/50 Hz) (no PD connected) • V2: 251.84 BTU/hr (220 V/50 Hz) (with 62 W PD connected) • V3: 263.6 BTU/hr (110 V/60 Hz) (with 62 W PD connected) |
| DESEMPEÑO | |
|---|---|
| Ancho de banda / plano posterior | 16 Gbps |
| Tabla de direcciones MAC | 8k |
| Memoria de búfer de paquetes | 4.1 Mbit |
| Marco Jumbo | 9 KB |
